| General | |||
|---|---|---|---|
| Frequency coverage | 136-174 MHz 400-470 MHz, 450-520 MHz |
||
| Number of channels | Max. 32 channels | ||
| Channel spacing | 6.25/12.5/25 kHz 7.5/15.0/30 kHz |
||
| PLL channel step | 2.5, 3.125 kHz | ||
| Frequency stability | ±0.5ppm | ||
| Operating temperature range | -30°C to +60°C -22°F to +140°F |
||
| Power supply voltage | 13.6V DC | ||
| Current drain (at 13.6 V DC) Tx Rx |
|
||
| Antenna impedance | 50Ω (Type-N × 2) | ||
| Dimensions (W×H×D) | 483 × 88 × 260 mm 191⁄32 × 315⁄32 × 101⁄4 in |
||
| Weight | 5.6 kg; 12.3lb (approx.) | ||
| Transmitter | |
|---|---|
| Output power | 50W (adjustable to 5W) 25W at 100% duty cycle |
| Max. frequency deviation | ±5.0 kHz/±2.5 kHz (wide/narrow) |
| Spurious emissions | 80dB typ. |
| Adjacent channel power | 73/67dB typ. (wide/narrow) |
| FM Hum and noise | 50/45dB typ. (wide/narrow) |
| Audio harmonic distortion | 1% typ. (40% deviation) |
| Microphone impedance | 600Ω (8-pin modular) |
| Receiver | |
|---|---|
| Sensitivity FM (W/N) Digital |
0.30µV typ. (at 12dB SINAD) 0.25µV typ. (at 5% BER) |
| Spurious response | 90dB |
| Intermodulation rejection ratio | 78dB |
| Hum and noise ratio | 50/45dB (wide/narrow) |
| Audio output power | 4.0 W typ. at 5% distortion with a 4 ohm load |
| External speaker connector | 2-conductor 3.5 (d) mm (1⁄8″)/4Ω |
Applicable U.S. Military Specifications
Icom makes rugged products that have been tested to and pased the following MIL-STD requirements and strict environmental standards.
| Standard | MIL 810F | |
| Method | Proc. | |
| High Temperature | 501.4 | I, II |
| Low Temperature | 502.4-3 | I, II |
| Dust | 510.4 | I |
| Vibration | 514.4 | I |
| Shock | 516.5 | I |
Also meets equivalent MIL-STD-810-C, -D and -E.
Measurements made in accordance with TIA-603 (for Analog FM). All stated specifications are subject to change without notice or obligation.
